4.4 Options
The options available for your machine are described below.
4.4.1 Option H1
Machine mountings
These mountings allow the machine to be anchored firmly to the floor.
Fig. 5 Machine mountings
4.4.2 Option K3
Cooling air filter mat
The mat filters the cooling air and keeps the cooler surface clean.
Fig. 6 Cooling air filter mat (option K3)
1 Cooling air filter mat
4.4.3 Option K2
Water-cooling
Plate heat exchangers in stainless steel are used for water-cooled machines. An additional container
supplements the cooling oil circuit.
This additional container is omitted on machines with heat recovery.
