Temperature measurement
1. Turn the rotary function switch to ℃/℉ position. Press "FUNC.” to select °C or °F, the display reflects the
chosen temperature unit.
2. Insert the K-type thermocouple into the meter, the positive pole (red) of the thermocouple into the INPUT
input and the negative pole (black) into the COM input.
3. Contact the thermocouple probe with the measurement object , then the reading appears on the display.
4. Connect the temperature probe with the testing point.
Warning
To avoid possible electric shock DO NOT apply the probe tip to any conductor that is greater than 30 V ac, 42 V
peak or 60 V dc to earth.
Note:
It takes a long time for the cold end of
thermocouple to be restored in the instrument
to achieve thermal balance with the environment.
19
