Bladder Volume Tester User’s Manual V1.02
- 18 -
2. Place the probe towards the direction of tailbone, press the scan key on the probe or touch
the key on the touch screen to scanning the image;
3. Touch patient mode key to select the desired mode: standard mode , obesity mode and
child mode ;
Description: Child mode is generally applicable to children for 6-12 years old.
Excessive weight and height of children can choose the standard mode.
4. After accurate positioning the bladder, press the scan key on the probe or touch the
key on the touch screen to freeze the image, the system will generate 12 frames
cross-sectional area and automatically draw the border of boarder, also show the bladder
volume;
5. Confirm the scanning results.
(1) If appears orange arrow above the projection, it indicates the measurement result is
unacceptable, the probe must be moved according to the arrow direction and re-scan to
measure again;
(2) If appears green arrow above the projection and displays the symbol “>” or “<” in the
measurement result, it indicates the measurement result is too small or too large but it is
acceptable, you need to slightly adjust the direction of probe and re-scan to measure
again;
(3) If no arrow appears above the projection, it indicates the measurement result is correct.
6. If appear the longer spikes or unclosed gap on the projection of bladder, touch the patient
mode key on the screen to optimize the edges of the image, the projection will be
automatically optimized and bladder volume will be automatically updated after processing.
7. If the measurement error is large, you can enter manual contour interface to observe the
images of large error to carry out manual contour, and then return to the main interface;
8. Touch key to save the patient measurement results;
9. Touch key to print the patient measurement results.
10.3 Manual contour
Due to the complexity of the patient population, as well as higher demands on accuracy by doctors,
the system provides the manual contour function.
For individual complex images having large error, the doctor can choose manual contour.
Directly touch large error image to enter manual contour interface, as follows:
Attention
:
To ensure the accurate measurement, please make sure:
1. There is no air gap between the probe and the patient’s skin when scanning, and use
appropriate pressure to keep the contact with the patient’s skin;
2. The stability of machine when scanning, avoid shaking cause the measurement error;
3. There is no catheter in the patient’s bladder, the presence of catheter may affect the
