6. Prog. Config and Data Summary
MAXICAL
®
III’s many functions are determined during program-
ming - which can be done either by Kamstrup A/S, your local
distributor, the heat supplier or by a service engineer.
Programming is divided into three groups: PROG, CONFIG and
DATA. Legal measuring parameters PROG may only be changed
when the program block is V=0.
A B C C C
Prog. No.
Flow meter placed in flow pipe 1
Flow meter placed in return pipe 2
Energy calculation in GJ 2
“ kWh (Qn £ 3m
3
/h) 3
“ MWh 4
Flow meter code
Qmax (only at CCC ³ 300) m³ /h
V
Prog-access denied
Accessible 0
Program access denied (can be verified) 1
