Kamstrup MAXICAL III - E< Configuring Multi-Tariff; H< Configuring Alarm Output; J< Configuring Analogue Outputs; K< Configuration of Pulse Dividers

MAXICAL
®
III5511-229 GB/98.06/Rev. B1
31
6.5 >E< Configuring Multi-Tariff
E= Tarif Type Tariff Limits
0 No active tariff -
1 Power controlled tariff TL2 < TL3
2 Flow controlled tariff TL2 < TL3
3 Cooling tariff TL3 < TL2
--
5 Return temperature tariff TL2 < TL3
6 Average temperature tariff -
7- -
8 Remote controlled tariff -
9 Clock controlled tariff TL2¹TL3
6.6 >H< Configuring Alarm Output
H= Alarm Output Alarm Limit
0 No active alarm -
1 Power controlled alarm AL
2 Flow controlled alarm AL
3 Cooling alarm AL
4 Flow temperature alarm AL
5 Return temperature alarm AL
6.7 >J< Configuring analogue outputs
J = Analogue outputs
0 No set up
1 A1=Power A2=Flow A3=t
F
A4=t
R
2 A1=Power A2=Flow A3=t
F
A4=Dt
6.8 >K< Configuration of pulse dividers
K Energy Water
0 1:1 1:1
1 10:1 1:1
2 1:1 10:1
3 10:1 10:1
