6.4 >DD< Configuration of Display Values
DD 50 51 52 53
Energy ***) 1 1 1 1
Water 2 2 2 2
Hour Counter 3 3 - 3
t
FLOW
4434
t
RETURN
5545
Dt6656
Power 7 7 6 7
Peak Power *) 8 8 - 8
Flow 9 9 7 9
Peak Flow *) 8 -
All Info - 10
Info (-2) **) 10 10 - -
TA 2 ***) A - A
TL 2 B - B
TA 3 ***) C - C
TL 3 D - D
Alarm limits A E - E
Customer ID No. B F A F
Current Date C G - G
Current Time D H - H
Quick Sum E I - I
Segment Test F J B J
*) Either peak power or peak flow can be displayed.
**) Info =128 does not exist in MAXICAL
®
III. When Info (-2)
is selected in the DD-code, the info code 2 alarm relay will
not be triggered, nor will “E” appear in the display.
***) Automatic display sequence at 5 s. interval.
Note:
Hour counter is running with mains supply only. (Operating hours)
