Kamstrup MAXICAL III - Page 29

MAXICAL
®
III5511-229 GB/98.06/Rev. B1
29
CCC Sep. Pre- Flow- No. of Decimals in the Display
No. counter factor kWh MWh GJ m
3
l/h m
3
/h kW MW Pulses/l Qmax (Qm)
300 10 18,000/Qm Qm x 4377 0 3 2 2 3 1 18,000/Qm 1.2-14
301 10 180,000/Qm Qm/10 x 4377 2 1 1 2 3 18,000/Qm 12-140
302 10 1.800,000/Qm Qm/100 x 4377 1 0 0 1 2 18,000/Qm 120-1400
303 10 18,000,000/Qm Qm/1,000 x 4377 0 x10 x10 0 1 18,000/Qm 1200-14000
CCC No. Flow signal Connection Jumper
0XX Slow Pulses 10-11 *)
1XX Fast Pulses 9-10-11 *)
3XX Frequency signal 75-76 *)
6.3 CCC-Table for MAXICAL
®
III
CCC-codes 300-303 are used for flow meters with active fre-
quency output, programmed to 5 kHz @ Qmax.
*) Please refer to chapter 4.6
Qm can be entered by means of the programming software, type
no. 66-99-210.
Example:
A flow meter with Qm=40 m³/h - corresponding to 5 kHz is
connected. In the software CCC is selected as 301 and Qm as
40 m³/h. With this setting, an integration is performed for every
0.1 m³ water. The accumulated energy in MWh is displayed with 2
decimals.
6.4 CCC-Table for MAXICAL
®
III
CCC-codes 310-313 are used for flow meters with active fre-
quency output, programmed to10kHz @ Qmax.
CCC Sep. Pre- Flow- No. of Decimals in the Display
No. counter factor kWh MWh GJ m
3
l/h m
3
/h kW MW Pulses/l Qmax (Qm)
310 10 36.000/Qm Qm x 2188 0 3 2 2 3 1 36.000/Qm 1,2-14
311 10 360.000/Qm Qm/10 x 2188 2 1 1 2 3 36.000/Qm 12-140
312 10 3.600.000/Qm Qm/100 x 2188 1 0 0 1 2 36.000/Qm 120-1400
313 10 36.000.000/Qm Qm/1.000 x 2188 0 x10 x10 0 1 36.000/Qm 1200-14000
