8. Programming Tariff and Alarm Limits
All tariff limits, alarm limits and analogue outputs measuring
values in MAXICAL
®
III must be programmed as digits and
decimals - but without the decimal point. Temperature limits (E=3
and E=5, H=3 and H=5 plus A3 and A4) must always be entered
in °C with two decimals. However, power and flow limits (E=1
and E=2, H=1 and H=2 plus A1 and A2) vary both with respect to
measuring unit and number of decimals, depending on the flow
meter code (CCC no.) selected.
Additionally, please note that:
TL3 must be larger than TL2 when you select code
E=1. 2 and 5
and,
TL3 must be smaller than TL2 if you select code E=3
( D t tariff).
Example 1:
DD
DD
Dt tariff (E=3)
TL2 = 30.00°C and TL3 = 20.00°C means that:
TL2 = 3000 and TL3 = 2000
Example 2: Power tariff (E=1)
TL2 = 10.0 kW and TL3 = 15.0 kW means that:
TL2 = 100 and TL3 = 150
