MULTICAL® 402
6.2 Mains modules
MULTICAL® 402 is vilble wih
supply modules for eiher 24 VAC or
230 VAC.
The modules re proecion clss
II nd re conneced vi  wo-wire
cble (wihou erh) hrough he
big cble bush, in he op lef of he
connecing bse. Use connecing
cble wih n ouer dimeer of 5-10
mm nd ensure correc sripping
of he cble s well s correc
mouning of cble relief.
If connecing o 230 VAC, i is
imporn o mke sure h he
whole insllion complies wih
curren regulions. The supply
cble o he meer mus no be
pre-fused by  bigger fuse hn
permied, see exmples below.
24 VAC supply
Blck
Red
24 VAC
97
98
3,6 V
N
L
24 VAC
E.g. rnsformer 230/24V,
ype 66-99-403, cn be used.
Note! MULTICAL® 402 cnno be
powered by 24 VDC.
230 VAC supply
Blck
Red
230 VAC
27
28
3,6 V
N
L
230 VAC
This module is used in connecion wih
direc mins connecion.
Note! Exernl supply my only be
conneced o he supply module.
Supply cable Max. Fuse
2 x 0,75 mm
2
(ccessory from Kmsrup A/S) 6 A
2 x 1,0 mm
2
10 A
In connecion wih oher ypes of insllions or requiremens for bigger
pre-fuses hn he ones lised bove, i is necessry o consul  cerified
elecricin for n individul evluion of how he ype of insllion in
quesion should be crried ou.
