Kamstrup MULTICAL 403 User Manual

2 Kmsrup A/S • 55121739_A4_GB_11.2017
MULTICAL® 403
Information
Permissible operating conditions / measuring ranges
Approved he meer in ccordnce wih MID nd EN1434:
Temperure Rnge q: 2 °C…180 °C DΘ: 3 K…178 K
Flow sensor (emperure of medium) qq: 2 °C…130 °C
Approved cooling meer in ccordnce wih DK-BEK 1178 nd EN1434:
Temperure Rnge q: 2 °C…180 °C DΘ: 3 K…178 K
Flow sensor (emperure of medium) qq: 2 °C…130 °C
MID designation
Mechanical environment
Clss M1 nd M2
Electromagnetic environment
Clss E1 (housing/ligh indusry). The meer’s conrol cbles mus be drwn  min. 25 cm
disnce from oher insllions.
Climatic environment
Non-condensing, closed locion (insllion indoors), mbien emperure 5…55 °C.
Maintenance and repair
The disric heing supplier cn replce emperure sensor pir, bery nd communicion
module. The flow sensor mus no be sepred from he clculor. Oher repirs require
subsequen reverificion in n ccredied lborory.
Selecting a temperature sensor pair
MULTICAL® 403-W - P500
MULTICAL® 403-T - P500
MULTICAL® 403-V - P100
Battery for replacement
Kmsrup ype 403-0000-0000-200 (1 x D-cell)
Kmsrup ype 403-0000-0000-100 (2 x AA-cell)
Communication Modules
For n overview of vilble modules we refer o secion 9, pge 18.

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
