KanexPro EXT-PROCTRL - 7 Connection Diagram

52
7. CONNECTION DIAGRAM
HDMI Cable
Encoder Mode
10G
POE
NETWORK
SWITCH
EXT-PROCTRL
Sources Displays
Projector
Decoder Mode
LAN Cable
Extend up to 120 meters (495 feet) over CAT6a
10G POE NETWORK SWITCH
EXT-PROCTRL
Multi Viewer TV Wall
x1 RX in this case
(for each screen)
x9 RX in this case
(for each screen)
EXT-PROMATRIXE XT-PROMATRIXXE
MouseKeyboard
