7
6.4 IR Cable Pinouts
6.5 RS-232 Pinout and Defaults
6.6 WebGUI Control
• Device Discovery
Please obtain the “Device Discovery” software from your authorized dealer and save it in
a directory where you can easily find it.
Connect the unit and your PC/Laptop to the same active network and execute the
“Device Discovery” software. Click on “Find Devices on Network” and a list of devices
connected to the local network will show up indicating their current IP address.
Note: This unit defaults to DHCP mode. The current IP address can be verified using the HDMI
output or RS-232 if the Device Discovery software is not available.
By clicking on one of the listed devices you will be presented with the network details of
that particular device.
