KANEXPRO MX-HDBASE4x4-4k
5 | P a g e
output for local monitoring.
e. HDBaseT: Works with HDBaseT receivers, such as
HDBASE70POER. It can extend AV, IR and RS232 signal
to 70m distance. Meanwhile, it can provide power for the
receivers which support PoC.
f. AUDIO: HDMI de-embedded stereo audio output
Connect with extended IR receiver, use the IR remote to
control MX-HDBASE4X4-4K.
TCP/IP port for unit control
Serial port for unit control, 9-pin female connector, connects
with control device such as a PC.
Illuminate red when powered on.
Connect with DC 24V power adaptor.
Connect to grounding, make the unit ground well.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.
