KanexPro MX-HDBASE4x4-4k - Panel Drawing

KANEXPRO MX-HDBASE4x4-4k
34 | P a g e
6 Panel Drawing
1 2 3 4
CLEAR
EDIDALL
INPUTS MENU
ENTER
IR
FIRMWARE
SYSTEM MONITOR
436.40 mm
23.10 mm
4
4
.0
0
m
m
3
1
.8
0
m
m
RS232
IR EYE
TCP/IP
HDMI INPUTS
IR OUT
1 2 3 4
1 2 3 4
OUTPUTS
HDMI
AUDIO
HDBaseT HDMI
2 3 4
L R
AUDIO
L R
AUDIO
L R
AUDIO
L R
Tx Rx Tx Rx Tx Rx
IR IN
1
IR IN IR IN IR IN
IR ALL IN
COAX
HDBaseT HDBaseT HDBaseT
DC 24V
COAX COAX COAX
Tx Rx
HDCP2 2.
