KANEXPRO MX-HDBASE4x4-4k
21 | P a g e
Command
Function
Feedback Example
with comma).
[x1]B[x2].
Transfer the AV and IR signal from input
channel [x1] to one or several output
channels ([x2], separate output channels
with comma).
AV: X1-> X2
(X1/X2=01~04)
[x1] R[x2].
Transfer the IR signal from output [x1] to
input [x2].
IR: X1-> X2(X1 、
X2=01~04)
Status[x].
Check the I/O connection status of output
[x]
AV: Y-> X
(X=01~04, Y=01~04)
Status.
Inquire the input channel to the output
channels one by one.
AV: 01->01
… …
AV: 04->04
IR: 01->01
… …
IR: 04->04
Save[Y].
Save the present operation to the preset
command [Y], ranges from 0 to 9.
Save To FY (Y=0-
9)
Recall[Y].
Recall the preset command [Y].
Recall From FY
(Y=0-9)
Clear[Y].
Clear the preset command [Y].
Clear FY
(Y=0-9)
PWON.
Work in normal mode.
PWON
PWOFF.
Enter into standby mode and cut off the
power supply to HDBaseT receivers.
PWOFF
STANDBY.
Enter into standby mode. (Do not cut off
the power supply to HDBaseT receivers,
press other buttons or send other
commands to start.)
STANDBY
/%[Y]/[X]:[Z].
HDCP management command.
[Y] is for input (value: I) or output (value:
O); [X] is the number of the port, if the
value of X is ALL, it means all ports; [Z] is
for HDCP compliant status, the value may
be 1 (HDCP compliant) or 0 (not HDCP
compliant).
/%[Y]/[X]:[Z].
DigitAudioON[
x].
Enable HDMI audio output of port x.
 X=1, 2, 3, 4, enable this port.
DigitAudio ON with [x]
