F. Antennas Technical Specifications
(1) ANT 200
ANT200 is a whip dual frequency antenna for aircraft up to 250 kts.
- Frequencies: 121.5 / 406 MHz.
- Impedance: 50 ohms.
- VSWR:
• 2.0:1 or better at 121.5 MHz.
• 1.5:1 or better at 406 MHz.
- Weight: 170 gr. max (0.375 lb).
- Temperature: -65°C to +71°C
- Connector: BNC female
- Mount: Ø 13 mm hole required (0.515 in.).
- Overall dimensions: 634.5 x 25 mm max (24.98 x 1 in.).
- Antenna height: 609.6 mm (24 in.).
- Speed rating: 250 Knots
Refer to 5. ANT200 Outline Dimensions, page 505.
(2) ANT 300
- Frequencies: 121.5 / 243 / 406 MHz.
- Impedance: 50 ohms.
- VSWR (relative to 50 ohms): ≤1.7:1
- Weight: 150 gr. (0.33 lb).
- Connector: BNC female.
- Overall dimensions: 342 x 122 x 62 mm ( 13.47 x 4.8 x 2.44 in.).
- Antenna height: 395 mm (15.56 in.).
- Speed rating: up to 300 - 350 kts
Refer to 6. ANT300 Outline Dimensions, page 506.
3. Equipment limitations
None
