KANNAD 406 AF-COMPACT
PAGE: 108
FEB 01/2008
F. Transmitter Technical Specifications
TYPE
• Two-frequency ELT
(121.5 / 406.028 MHz)
• Automatic fixed
• COSPAS-SARSAT Category II
(-20°C to +55°C).
406 MHz TRANSMISSION
• Frequency: 406.028 MHz+/-1 kHz
• Output power: 5W (37 dBm +/- 2 dB)
• Modulation type: 16K0G1D
(Biphase L encoding)
• Transmission duration:
440ms (short message) every 50
sec.
• Autonomy: Over 48 hours at
-20°C
121.5 MHz TRANSMISSION
• Frequencies:
121.5 MHz +/- 6 kHz
• Output power: 100 to 400 mW
(20dBm to 26 dBm)
• Modulation type: 3K20A3X
• Modulation rate: > 85 %
• Frequency of modulation signal:
1420 Hz to 490 Hz with decreasing
sweep
• Autonomy: Over 48 hours at
-20°C
CONTROLS
• ARM / OFF / ON switch
• Bright red visual indicator
• BNC antenna connector
• DIN12 socket for remote control
panel (RCP) and pin programming
option.
•Buzzer
G-SWITCH SENSOR
Mechanical G-switch sensor compliant
with EUROCAE ED62 specifications
BATTERY
KIT BAT200, P/N: S1840510-01
LiMnO
2
two-element battery for
transmitter power supply
Replacement every 6 years
HOUSING
Material: Polycarbonate
Color: Yellow (color compounded)
Transmitter dimensions:
131 x 86 x 75.4 mm
( 5.157 x 3.385 x 2.968 inches)
Overall dimensions:
max 140 x 98 x 86.4 mm
(5.512 x 3.858 x 3.4 inches)
Weight including batteries:
• typical 850 gr. (1.874 lb);
• max 875 gr. (1.929 lb).
Tightness: O-rings
ENVIRONMENTAL CONDITIONS
RTCA DO-160E / EUROCAE Section 4
to 26:
[ED62]X[ED62]A[ED62][SYLMC]EYXXX
XZXXX[ZC][ED62]B[XXXXX]XXX[ED62]
QUALIFICATIONS
ETSO-2C91a & ETSO-2C126 (EASA)
TSO-C126
COSPAS-SARSAT TAC N° 167
FOR USE OUTSIDE OF THE USA OR
EASA RULES, CONTACT YOUR
LOCAL CIVIL AVIATION AUTHORITY.
