INSTALLATION MANUAL OPERATION MANUAL INSPECTION LOG
KANNAD 406 AF-COMPACT
PAGE: 106
FEB 01/2008
E. Transmitter Technical characteristics
(1) Mechanical characteristics
The ELT housing is to be installed on a Mounting Bracket (P/N S1840502-
01).
(2) Material
- Material: Polycarbonate.
- Treatment: Light yellow color (RAL 1018), Fire classification M0.
(3) Overall Dimensions
Refer to 1. ELT Outline Dimensions, page 501
- Transmitter outline dimensions: 131 x 86 x 75.4 mm (5.157 x 3.385 x
2.968 inches).
- Outline dimensions with mounting bracket: 140 x 98 x 86.4 mm (5.512 x
3.858 X 3.40 inches).
(4) Weight
- Typical: 850 gr (1.874 lb).
- Max.: 875 g.r (1.929 lb).
(5) Electrical characteristics
Transmitter power supply: LiMnO
2
two-element battery.
(6) Electrical interface
When installed onboard, the ELT has to be connected:
- to RC200 Remote Control Panel via a DIN12 socket (J1);
- to an outside antenna via a BNC female connector (J2).
The DIN12 socket is also used to connect programming dongle or
programming and test equipment.
