INSTALLATION MANUAL OPERATION MANUAL INSPECTION LOG
KANNAD 406 AF-COMPACT
PAGE: 207
FEB 01/2008
C. ELT installation procedure
1. Mount the transmitter on the bracket "Flight direction" arrow pointed
towards the front of the aircraft (Figure 202: KANNAD 406 AF-
COMPACT, axis of installation).
2. Slide the self-stripping strap through the buckle. Ensure the buckle is
correctly positioned (indifferently on right or left side of ELT)
regarding the horizontal center line of ELT as shown Detail A.
3. Fasten the self-stripping strap tightly.
Figure 204: Installing the transmitter on the bracket
