DN1769-1809
18
2 - Technical Specifications
Table 1: Technical Specifications
Specification Description
AC Power Input (UL) 16.5 VAC, 40 VA, 1.9 Amps class 2 transformer, see Table 3 on page 28 for the part
numbers
DC Power Input (CE) 19 VDC, 3.15 Amps, see Table 3 on page 28 for the part numbers
DC Auxiliary Output 11.2 to 13.75 VDC, 450 mA
Lock Output 11.2 to 13.75 VDC, 650 mA
Relay Controlled Outputs • 3 Form C Relay controlled outputs
• 30 VDC, 3 Amps max each, or
• 24 VAC, 3 Amps max each
Reader Power Outputs
(JP9)
3 options with jumpers (JP9):
• 5 VDC, 175 mA, or
• 12 VDC, 175 mA, or
• from external controller
Auxiliary Reader Outputs 2 outputs per reader (LED and BUZ), 25 mA max. each, open collector outputs
Reader types Wiegand interface
Monitored Points
(Zone Inputs)
• 4 monitored points (Z1 to Z4), NO/NC, with or without EOL resistor
• 1 fixed-function tamper switch input
Points maximum wiring AWG #22 - 600 m (2,000 ft.)
Weight (UL Listed) 7.0 kg (15.4 lb)
Weight (CE Compliant) 7.0 kg (15.4 lb)
Visual User Interface (VUI)
Characteristics
4 lines x 20 Characters LCD module with controllable LED backlighting.
The text on the 4th line cant be edited, but can be changed with the navigation buttons.
Operating Temperatures Without heater kit: -10°C to 55°C (14°F to 131°F)
With heater kit: -40°C to 55°C (-40°F to 131°F)
Humidity Level Indoor and outdoor: 0 to 90%
Storage Conditions Temperature: -40°C to 70°C (-40°F to 158°F)
Multiple KTES Cabling Telephone Line: 305 m (1,000 ft.) maximum
RS-485 Bus: 1219 m (4,000 ft.) maximum
Ethernet network: 91 m (300 ft.) maximum
KTES Dimensions
(Surface Mount)
29.21 cm (11 1/2 in.) Wide x 37.46 cm (14 3/4 in.) High x 9.91 cm (3.9 in.) Deep
Communication ports 10/100 Base-T Ethernet Port (RJ-45 connector)
1 x RS-485 (COM1)
Global Data Access Arrangement (DAA) interface for the telephone line
Communication speed • Ethernet: 10/100 Base-T
• RS-485: from 1200 to 115,200 Baud (automatic detection)
• Dialup Modem: Up to 2400 Baud
Flush Mount Box 30.33 cm (12 in.) Wide, 38.42 cm (15 1/8 in.) High, 7.15 cm (2 7/8 in.) Deep
Paper Index Flush Mount 29.21 cm (11 1/2 in.) Wide, 37.46 cm (14 3/4 in.) High, 2.82 cm (1 1/8 in.) Deep
