10.3 Tools and aids
4
Hexagon socket screwdriver
(SW 4 / 60 mm)
PH2
Standard Phillips screwdriver (PH2)
↵
Finally acknowledge a process by press-
ing the Start button (interior control panel).
Number of qualified, trained and autho-
rized service technician required for this
maintenance task.
The following chapters describe the work steps
required for carrying out maintenance and care
actions.
At the beginning of each chapter, the required tools
and aids are depicted, unless the corresponding
process can be carried out by one individual person
without any further auxiliary equipment.
The assembly is basically carried out in
reverse order of the disassembly.
Exceptions are especially pointed out.
If you open the bed part or one of the
acrylic panes, you must, after clos-
ing, acknowledge a warning message
appearing on the interior control panel.
10.4 Unlocking the bed
↵
①
②
①
⇒
Fold up the canopy.
①
Reach into the lower gap positioned in the
middle of the front panel.
②
Drag release button.
⇒
Tilt up the bed.
