KBL 4800 alpha - 12 Technical Data

Ambient conditions
Installation site
• In dry rooms (booths) with sufficient airing and
ventilation
• Maximum relative air humidity: ≤ 70 %
• Maximum room temperature: ≤ 86°F (30°C)
• Minimum height of the room: ~74,02 inches
• Only on a non-combustible basement
• Maximum operating altitude: ≤ 6500 ft
Weights and measures
Dimensions in inches
(Height x width x depth)
~53,94 x ~91,74 x ~62,21 (when closed)
~67,33 x ~91,74 x ~56,70 (when open)
Bed pane
max. load capacity
330 lbs
Weight
~1190 lbs
Electrical connection values
Protective class
IP20
Mains voltage
3-phase: 3 x 220 V / ~ / 60 Hz
Wire cross section
3-phase: 4 x AWG8
THHN cable in a isolation tubing (e.g. flexible metallic conduit, utilizing appropriate connectors)
Fuses
See unit data - For Canada all tanning devices with Class-A ground fault circuit interrupter GFCI
MP3-Player
• Supports SD cards up to 1-2 GB (SD) / 4-16 GB (SDHC)
• Supported file system (SD card): FAT16, FAT32
• Supported MP3 files: constant and variable bit rate, 96-320 Kbit/s
Central exhaust air
Fan / blower
Exhaust-air socket Ø ~11,81" - Height to top ~61,54" (with and without hot air recirculation) - Minimum
exhaust air flow rate: 2250 m
3
/h (594400 gal/hour)
Exhaust air duct hose
Ø 300mm (~11,81")
UNIT DATA - KBL 4800 alpha
Electronic Power - P2 (KBL 4800 - 40p2/3a - 1616 ep u_us)
Item no
Tubes
Canopy:
Bed:
22x pureSunlight 1825 R 160W
2x extraSunlight 1857 R 80W
16x pureSunlight 1900 R 180W
3230075125
3230074881
3230075155
Face tanner 3x megaLine HP 500 4230304000
Filter panes 3x EVO 19176 3020019176
Nominal power With air conditioning: 10000W / Without air conditioning: 8600W
Fuses 3-phase: 3 x 40 A
12. Technical data
Operating Instructions | KBL 4800 alpha
53
