3 Control and Display Panel
Operating elements:
1 LCD displaying the current status and user prompts
2 Number of possible controller output lines
3 Two sensor buttons for parameter conguration
4 Two sensor buttons for menu selection
multicomp F144-3 Eco 6-stage
multicomp F144-3 Eco 12-stage
