KBR multicomp F144-MS-1V1C1TI6RO-3 User Manual

V2.01
25359_EDEBDA0279-2320-1_EN
60
Address Words Description Unit Format
0x0002 2 Voltage V oat
0x0004 2 Current A oat
0x0006 2 Network frequency Hz oat
0x0008 2 Current CosPhi oat
0x000a 2 Active power W oat
0x000c 2 Fundamental reactive power var oat
0x000e 2 No compensation power var oat
0x0010 2 Apparent power VA oat
0x0012 2 THD % oat
0x0014 2 Temperature °C oat
0x0016 2 Overtemperature switch-o oat
0x0018 2 Voltage 3
rd
harmonic % oat
0x001a 2 Voltage 5
th
harmonic % oat
0x001c 2 Voltage 7
rd
harmonic % oat
0x001e 2 Voltage 9
rd
harmonic % oat
0x0020 2 Voltage 11
rd
harmonic % oat
0x0022 2 Voltage 13
rd
harmonic % oat
0x0024 2 Maximum missing compensation power var oat
0x0026 2 Relay states (12 bit: bit 0 = stage 1 - bit
11 = stage 12 // bit 13 = error message)
bitwise unsigned
long
0x0028 2 Messages (bit coded) unsigned
long
0x002a 2 Error messages (bit coded) unsigned
long
14.5 Data points
Data points can be read via the command 0x04 (read input registers) in accordance with
table 1.
Data point description for the Modbus protocol
