V2.01
25359_EDEBDA0279-2320-1_EN
15
Control and display panel
Error message dialog:
No measuring voltage The settings Message or
No stage power Alarm relay or Message and
Facility too small Alarm relay or O
THD too high is identical for all errors!
Operating cycle limit exceeded
No measuring current
Light load
Temperature switch-o
Extras:
Display language German, English, French, Spanish
THD limit 0 to 10%, harmonics monitoring can be disabled
(0%)
Operating cycle limit 0 to 999999 (0 = deactivated)
Sampling rate Automatic, xed 50 Hz, xed 60 Hz
Stage power monitoring Yes, No
Reset Run
Contrast setting 0 to 10
Brightness setting 0 to 9
Dimmer brightness 0 to 9
Low-load limit 15 mA, 50 mA
Light load delay 1 minute to 60 minutes
Temperature measurement On / O
Relay 6 or 12
(depending on the controller version) Compensation stage, fan relay
Alarm relay Error message, fan relay
Fan switch on temperature > 0 °C to 60 °C
Fan switch o temperature < 0 °C to 60 °C
Switching threshold system o > 0 °C to 60 °C
System switch on temperature < 0 °C to 60 °C
Bus mode Modbus (eBus for production)
Learning mode menu display On / O
Key sounds On / O
