NOTE

A voltage transformer must be used here with no phase shift between current and volt-

age, as the device is not able to compensate this.

Setting the discharge time:

Checking or, if necessary, changing the discharge time of the capacitor stages is a very

important menu item. You can set the discharge time from 0 to 999 sec. Please make sure

that the correct value is set, otherwise the capacitors could be damaged.

Conguring the capacitor stages:

There are two ways of conguring the capacitor stages. The stages can be congured

manually or using the auto conguration mode.

NOTE

The Auto conguration mode menu will not appear

if the "Learning mode" is deactivated in the "Extras" menu

It is important to set the stage power correctly. You can nd the stage power on the

nameplate of the stage or the circuit diagram and then program it manually. In this case,

skip the menu item "Learning mode activate" and enter the power value individually for

each stage.

If you want to activate the learning mode, you have to make sure that all previous sub-

menu parameters have been set correctly.

To activate learning mode, press U, change the setting to Yes by pressing V, then press

X to conrm.

The auto conguration then automatically sets the stage powers and discharge times,

but these values need to be checked once the learning process has been completed to

ensure that they are correct.

NOTE

If an error occurs in auto conguration mode (harmonics exceeding the limit, measuring

voltage too high, missing measuring voltage), the process is interrupted and "Auto con-

guration mode – Error" is displayed. Auto conguration mode can be restarted once the

cause of the error has been rectied.

Description of the display window
