KE2 Compressor Sequencer OEM pn 21768
Quick Start Guide
Crical Alarms & Cauonary Alarms
Abbre-

Alarm  
A01 Sucon Pres Sensor [Group 1] Alarm
Group 1 sucon pressure sensor is shorted, open or pressure out of
range.

A02 Disch Pres Sensor [Group 1] Alarm
Group 1 discharge pressure sensor is shorted, open or pressure out
of range.

A03 Sucon Temp Sensor [Group 1] Alarm Group 1 sucon temperature sensor is shorted or open.

A04 Disch Temp Sensor [Group 1] Group 1 discharge temperature sensor is shorted or open.

A06 High Superheat [Group 1] Alarm
Group 1 sucon superheat is higher than Max Sucon SH for longer
than Min/Max SH Del.
A07 Low Superheat [Group 1] Alarm
Group 1 sucon superheat is lower than Min Sucon SH for longer
than Min/Max SH Del.

A08 High Disch Temp [Group 1] Alarm
Group 1 discharge temperature is higher than Max Disch Temp for
longer than Max Dis Tmp Del.

A09 High Int Comp Temp [Group 1] Alarm
Group 1 digital compressor internal temp high. Will turn o digital
compressor unl temp lowers.
A10 High Disch Pres [Group 1] Alarm
Group 1 discharge pressure is higher than Max Disch Pres for longer
than Max Dis Prs Del.

A13 Comp Mod [Group 1] Alarm Group 1 Compressor Module digital input is acve.
A16 Oil Safety [Group 1] Alarm Group 1 Oil Safety digital input is acve.
A19 Hi Pres Safety [Group 1] Alarm Group 1 High Pressure Safety digital input is acve.
A22 Aux Brd Comms Alarm Main Board unable to communicate with the Aux Relay Board(s).

A25 Watchdog Alarm Contact KE2 Therm.
A26 Email Failure Alarm
Email alert was not conrmed by email server provided aer seven
consecuve aempts.
A28 High Disch Temp [Group 2] Alarm
Group 2 discharge temperature is higher than Max Disch Temp for
longer than Max Dis Tmp Del.

A29 Evap Comms [Group 1] Alarm Group 1 SiteView controllers not communicang.
A30 Evap Comms [Group 2] Alarm Group 2 SiteView controllers not communicang.
A31 Disch Pres Sensor [Group 2] Alarm
Group 2 discharge pressure sensor is shorted, open or pressure out
of range.

A32 Sucon Temp Sensor [Group 2] Alarm Group 2 sucon temperature sensor is shorted or open.

A34 High Superheat [Group 2] Alarm
Group 2 sucon superheat is higher than Max Sucon SH for longer
than Min/Max SH Del.
A35 Low Superheat [Group 2] Alarm
Group 2 sucon superheat is lower than Min Sucon SH for longer
than Min/Max SH Del.

A36 Disch Temp Sensor [Group 2] Alarm Group 2 discharge temperature sensor is shorted or open.

A37 High Int Comp Temp [Group 2] Alarm
Group 2 digital compressor internal temp high. Will turn o digital
compressor unl temp lowers.
A38 High Disch Pres [Group 2] Alarm
Group 2 discharge pressure is higher than Max Disch Pres for longer
than Max Dis Prs Del.

Alarms - All Groups
Alarm Severity
Red LED - Critical Alarm: The controller will attempt to safely pump down the suction group. The group is unable to run safely with a critical
alarm, and the controller will cease refrigeration for that group. The controller is attempting to prevent a catastrophic system failure, such as
damage to the compressors. Critical alarms should be addressed immediately.
Yellow LED - Cautionary Alarm: The controller will continue to function to the best extent possible given the system conditions, but the
alarm should be addressed as soon as possible.
