Q.2.60 March 2019
Page 29
© Copyright 2019 KE2 Therm Solutions, Inc., Washington, Missouri 63090
KE2 Compressor Sequencer OEM pn 21768
Quick Start Guide
Click the icon to bring up
a real time view of the rack.
Click the bell icon to
view current alarms.
Flashing red = Critical
Yellow = Cautionary
Click to display controller
information (Location, IP
address, MAC address,
Firmware version.)
Example of Mobile View
Brings up the
Status page
for that Aux
Relay Board
Brings up the
Status page
for that Aux
Relay Board
Brings up the
Setpoints page for
that Suction Group.
Brings up the
Setpoints page for
that Suction Group.
KE2 Therm contact
information and link
to website
Description:
From the Home page, the user can access the Status & Setpoints page for the Main Board, as well
as the Status page for any Auxiliary Relay Boards.
Home Page
Home Page
