KE2 Compressor Sequencer OEM pn 21768
Quick Start Guide
Remote Display - Variables Menu - Dual Group
When not in a menu, press or to go through the Variables abbreviations.
Press to view a Variable in real time.
Press
to return to the previous screen.
Abbrev. Full Name Descripon
Pr1  Group 1 Sucon Pressure as read by the controller.
SU1  Group 1 Sucon Temperature as read by the controller.
SA1  Group 1 Saturated Sucon Temperature as calculated by the controller.
SH1  Group 1 Sucon Superheat as calculated by the controller.
dP1  Group 1 Discharge Pressure as read by the controller.
dt1  Group 1 Discharge Temperature as read by the controller.
dS1

GROUP1
Group 1 Discharge Saturaon Temperature as calculated by the controller.
dH1  Group 1 Discharge Superheat as calculated by the controller.
Pr2  Group 2 Sucon Pressure as read by the controller.
SU2  Group 2 Sucon Temperature as read by the controller.
SA2  Group 2 Saturated Sucon Temperature as calculated by the controller.
SH2  Group 2 Sucon Superheat as calculated by the controller.
dP2  Group 2 Discharge Pressure as read by the controller.
dt2  Group 2 Discharge Temperature as read by the controller.
dS2

GROUP2
Group 2 Discharge Saturaon Temperature as calculated by the controller.
dH2  Group 2 Discharge Superheat as calculated by the controller.
iP1  First three digits of the IP address.
iP2  Second three digits of the IP address.
iP3  Third three digits of the IP address.
iP4  Fourth three digits of the IP address.
Fir  Current rmware version on the controller.
Remote Display - Setpoints Menu - Dual Group
When not in a menu, press and hold until SA is shown.
Press
or to go through the setpoint abbreviations.
Press
to view the current setpoint value. Press or to change the setpoint.
Press and hold to save.
For numerical setpoints, pressing once will change the digit that is being modied.
Press
to return to the previous screen. When viewing a setpoint value, press to return to the previous screen without saving.
Abbrev. Full Name Min Max Default Descripon
SA KE2 SMART ACCESS diS EnA diS
Turn KE2 Smart Access on or o: EnA to enable / diS to disable
KE2 Smart Access.
dHC  diS EnA diS
Turn DHCP mode on or o: EnA to enable / diS to disable DHCP
mode.
Sy1  oF1 on1 oF1
Allow group 1 to run or put into system o: on1 to run / oF1 to
pump down group 1 and put into system o.
Sy2  oF2 on2 oF2
Allow group 2 to run or put into system o: on2 to run / oF2 to
pump down group 2 and put into system o.
PS1

GROUP1
0.0 psig
150.0
psig①
25.0
psig②
Target Sucon Pressure - Sucon pressure the controller will work
to maintain for group 1.
PS2

GROUP2
0 psig
150.0
psig①
25.0
psig②
Target Sucon Pressure - Sucon pressure the controller will work
to maintain for group 2.
CLA CLEAR ALARMS Press and hold ENTER to clear all acve alarms.
PAS  Press and hold ENTER to reset browser password.
①
R-410A = 300.0 psig, R-744 = 500.0 psig. ② R-744 =250.0 psig
