KE2 Compressor Sequencer OEM pn 21768
Quick Start Guide
Webpage Setpoints - Main Board (connued)
The following setpoints are available on the broswer interface of the Main Board.
Setpoint   Default

SUCT PRESS OFFSET
An oset added or subtracted from the sucon pressure
transducer reading, if needed.
-5.0 psi to 5.0 psi 0 psi
SUCT TEMP OFFSET
An oset added or subtracted from the sucon tempera-
ture sensor reading, if needed.
-5.0 to 5.0 0
DISCH PRESS OFFSET
An oset added or subtracted from the discharge pressure
transducer reading, if needed.
-5.0 psi to 5.0 psi 0 psi
DISCH TEMP OFFSET
An oset added or subtracted from the discharge tem-
perature sensor reading, if needed.
-5.0 to 5.0 0


An oset added or subtracted from the Input 1 tempera-
ture sensor reading, if needed.
-5.0 to 5.0 0


An oset added or subtracted from the Input 2 tempera-
ture sensor reading, if needed.
-5.0 to 5.0 0


An oset added or subtracted from the Input 3 tempera-
ture sensor reading, if needed.
-5.0 to 5.0 0
PID
PROPORTIONAL CMP
Should not be adjusted unless instructed to by KE2 Therm
technical support.
0 to 255 1
INTEGRAL CMP 0 to 255 1
DERIVATIVE CMP 0 to 255 0
PID TIME CMP 0 second to 255 seconds 1 second
Alarms
MIN SAFETY SUC SH
Minimum Safety Sucon Superheat. Provides a warning
that sucon line is low SH before triggering a crical low
SH alarm.
0.0°F to 50.0°F (0.0°C to 27.8°C) 0.0°F
MIN SUCTION SH
Minimum Sucon Superheat. The lowest acceptable
superheat for the sucon line. Turns system o when
exceeded longer than Min/Max SH Del.
5.0°F to 50.0° F (2.8°C to 27.8°C) 15.0°F
MAX SAFETY SUC TMP
Max Safety Sucon Temp. Provides a warning that suc-
on line temp is high.
5.0°F to 90.0°F (-15.0°C to 32.2°C) 90.0°F
MAX SUCTION SH
Max Sucon Superheat. Provides a warning that sucon
SH is high when exceeded longer than Min/Max SH Del.
25.0°F to 200.0°F (13.9°C to 111.1°C) 50.0°F
MAX SAFETY PRESSURE
Max Safety Discharge Pressure. Discharge pressure above
this value triggers High Safety Discharge Pressure alarm.
Group will stop loading stages, and begin to unload.
0.0 psig to 500.0 psig 400.0 psig

Min/Max Superheat Alarm Delay. Amount of me before
a Min Sucon SH or Max Sucon SH alarm is triggered
aer exceeding the threshold.
0 to 254 minutes
*Type 255 or ‘dis‘ and save to disable. Disabled
MAX DISCH TEMP
Maximum Discharge Temp. Triggers alarm and turns
system o when discharge temp exceeds this value longer
than Max Dis Tmp Del.
25.0°F to 300.0°F (-3.9°C to 148.9°C) 268.0°F
MAX DIS TMP DEL
Max Discharge Temp Delay. The amount of me before
an alarm is iniated when Max Disch Temp is exceeded.
0 to 254 minutes
*Type 255 or ‘dis‘ and save to disable. Disabled
MAX DISCH PRES
Maximum Discharge Pressure. Triggers alarm and turns
system o when discharge pressure exceeds this value
longer than Max Dis Pres Del.
100.0 to 500.0 psig 450.0 psig
MAX DIS PRS DEL
Max Discharge Pressure Delay. The amount of me
before an alarm is iniated when Max Disch Pres is
exceeded.
0 to 254 minutes
*Type 255 or ‘dis‘ and save to disable. Disabled
① Only one variable speed or digital scroll compressor can be selected per group.
② Function not currently implemented in most applications.
