KE2 Compressor Sequencer OEM pn 21768
Quick Start Guide
Alphabecal List of Abbreviaons (connued)
 Full Name Type 
S11
S11
Low Safety SH 2 [Group 2] Alarm Alarms - Safety / Preempve
Group 2 sucon superheat is below Min Safety Suc SH for
more than 5 minutes.
S12
S12
High Safety Suc Temp 2 [Group 2]
Alarm
Alarms - Safety / Preempve
Group 2 sucon temperature is above Max Safety Suc Tmp
for more than 5 minutes.
S13
S13
High Safety Disch Pres 2 [Group 2]
Alarm
Alarms - Safety / Preempve
Group 2 discharge pressure is above Max Safety Pres-
sure. Controller will aempt to unload stages and not load
anymore stages unl pressure is well below Max Safety
Pressure.
SA
SA
KE2 Smart Access
Setpoints - Single Group
Setpoint - Dual Group
Turn KE2 Smart Access on or o: EnA to enable / diS to dis-
able KE2 Smart Access.
SA1
SA1
 Variables - Dual Group
Group 1 Saturated Sucon Temperature as calculated by the
controller.
SA2
SA2

Variables - Dual Group
Variables - Dual Group
Group 2 Saturated Sucon Temperature as calculated by the
controller.
SAt
SAt
 Variables - Single group
Saturated Sucon Temperature as calculated by the
controller.
SH1
SH1
Superheat - Group1 Variables - Dual Group Group 1 Sucon Superheat as calculated by the controller.
SH2
SH2
Superheat - Group2 Variables - Dual Group Group 2 Sucon Superheat as calculated by the controller.
SHt
SHt
Superheat Variables - Single group Sucon Superheat as calculated by the controller.
SU1
SU1
 Variables - Dual Group Group 1 Sucon Temperature as read by the controller.
SU2
SU2
 Variables - Dual Group Group 2 Sucon Temperature as read by the controller.
SUt
SUt
 Variables - Single group Sucon Temperature as read by the controller.
Sy1
SY1
SY2
 Setpoint - Dual Group
Allow group 1 to run or put into system o: on1 to run / oF1
to pump down group 1 and put into system o.
Sy2
SY1
SY2
 Setpoint - Dual Group
Allow group 2 to run or put into system o: on2 to run / oF2
to pump down group 2 and put into system o.
SyS
SY1
SY2
 Setpoints - Single Group
Allow rack to run or put into system o: on to run / oFF to
pump down rack and put into system o.
