19
Technical Data 460V Class continued
Technical Data
1) The wire gauge is based on the maximum fuse rating, copper wire with minimum 75°C insulation rating, THHW or equivalent.
If branch circuit protection is selected based on rated input current, the wire size could be reduced.
2) With the regulated systems F5-M as well as F5-S 5% must be subtracted as control reserve
3) Rated operation means, rated input voltage, rated output current, and rated carrier frequency.
4) This data is only valid for units with internal brake transistor GTR 7 (see "unit identification")
5) The maximum cable length is the same for all carrier frequencies.
Inverter Size 20 21 22 23 24
Recommended Motor Power [hp] 50 60 75 100 125
Housing size RRRRRRUUU
Input Ratings
Supply voltage [V] 305...500 ±0 (460 V Nominal voltage )
Supply voltage frequency [Hz] 50 / 60 +/- 2
Input phases33333
Rated input current [A] 72 85 106 136 172
Recommended maximum input fuse [A] 80 100 125 175 200
Recommended wire gauge
1)
[awg] 4 3 1 2/O 3/O
Output Ratings
Rated output power [kVA] 52 62 80 104 125
Rated motor power[kW]3745557590
Rated output current [A] 65 77 96 124 156
Peak current (30 seconds)
2)
[A] 112 135 172 225 270
Over current fault (E.OC) trip level [A] 135 162 207 270 324
Overload curve (see annex) 1
Output voltage [V] 3 x 0…Vsupply
Output frequency [Hz]
Generally 0 to 1600Hz (limited by control board and carrier frequency)
Rated switching frequency [kHz] 8 4 8 4 8 2 8 4 8
Maximum switching frequency [kHz] 16 16 16 16 16 12 8 8 8
Power loss at rated operation
3)
[W] 900 1000 1100 1200 1500 1300 1900 2000 2400
Stall current at 4kHz [A] 75 90 90 115 115 128 150 180 180
Stall current at 8kHz [A] 75 63 90 80 115 90 150 117 180
Stall current at 16kHz [A] 34 45 54 46 51 – – – –
Braking Circuit
Min. braking resistance
4)
[Ohm] 9 9 9 6 5 4
Typ. braking resistance
4)
[Ohm] 13 11 9 6 6 6
Max. braking current [A] 88 88 88 133 160 200
Installation Information
Max. shielded motor cable length
5)
[ft]
165
Tightening torque for terminal strip [in lb] 53 133
Environmental
Max. heat sink temperature TOH [°C] 90°C / 194°F
Storage temperature [°C] -25...70 °C / -13…158°F
Operating temperature [°C] -10...45 °C / 14…113°F
Housing design / protection Chassis / IP20
Relative humidity max. 95% without condensation
Approvals
Tested in accordance with… EN 61800-3 /UL508C
Standards for emitted interference EN 55011 Class B / EN 55022 Class A
Standards for noise immunity IEC 1000-4-2 / -3 / -4 / -5/ -6
Climatic category 3K3 in accordance with EN 50178
