22
CP-Parameter
This parameter determines the reaction of the drive to terminal X2A.14 (F) and/or
X2A.15 (R), which are programmed as limit switches. The reaction of the drive is shown
in the table below.
CP.35 Reaction to limit switch
CP.36 Reaction to external fault
With the external error monitoring external units can take direct influence on the drive.
This parameter determines the response of the drive to a signal at terminal X2A.12 (I3)
according to following table.
CP.35 Display Response
0 E.PRx Immediate disabling of modulation
1 A.PRx Quick stopping / disabling of modulation after reaching
speed 0
2 A.PRx Quick stop / holding torque at speed 0
3 A.PRx Immediate disabling of modulation
4 A.PRx Quick stopping / disabling of modulation after reaching
speed 0
5 A.PRx Quick stop / holding torque at speed 0
6 none No effect to the drive; fault is ignored !
Restart
Remove fault;
reset
Autoreset, if no
fault is present
inapplicable
CP.36 Display Response
0 E.EF Immediate disabling of modulation
1 A.EF Quick stopping / disabling of modulation after reaching
speed 0
2 A.EF Quick stop / holding torque at speed 0
3 A.EF Immediate disabling of modulation
4 A.EF Quick stopping / disabling of modulation after reaching
speed 0
5 A.EF Quick stop / holding torque at speed 0
6 none No effect to the drive; fault is ignored !
Restart
Remove fault;
reset
Autoreset, if no
fault is present
inapplicable
