EN - 29
CP-Parameters
5.2 Parameter description for Multi and Application with encoder interface
Display Parameter Setting range Resolution Default Unit ENTER Based on
CP.00 password input 0...9999 1 – – – ud.01
CP.01 encoder 1 speed ±4000 0,125 0 rpm – ru.09
CP.02 set value display ±4000 0,125 0 rpm – ru.01
CP.03 inverter state 0...255 1 0 – – ru.00
CP.04 apparent current 0...6553,5 0,1 0 A – ru.15
CP.05 peak apparent current 0...6553,5 0,1 0 A – ru.16
CP.06 actual torque display ±10000,00 0,01 0 Nm – ru.12
CP.07 actual DC voltage 0...1000 1 0 V – ru.18
CP.08 peak DC voltage 0...1000 1 0 V – ru.19
CP.09 Output voltage 0...778 1 0 V – ru.20
CP.10 speed control cong. 0(off)...5 1 0 (off) – – cs.00
CP.11 DASM rated speed 0...32000 1 LTK rpm – dr.24
CP.12 DASM rated frequency 0,0...1600,0 0,1 LTK Hz – dr.25
CP.13 DASM rated current 0,0...1100,0 0,1 LTK A – dr.23
CP.14 DASM rated voltage 120...830 1 LTK V – dr.02
CP.15 DASM rated cos (phi) 0,50...1,00 0,01 LTK – – dr.04
CP.16 DASM rated power 0,10...1000,00 0,01 LTK kW – dr.03
CP.17 load mot. dependent parameter 0...3 1 1 – E fr.10
CP.18 Boost 0,0...25,5 0,1 LTK % – uf.01
CP.19 rated frequency 0...400 0,0125 50 Hz – uf.00
CP.20 encoder 1 (inc/r) 1…65535 1 2500 Inc E ec.01
CP.21 encoder 1 rotation 0...19 1 0 – E Ec.06
CP.22 max. reference 0...4000 0,125 2100 rpm – op.10
CP.23 step value 1 ±4000 0,125 100 rpm – op.21
CP.24 step value 2 ±4000 0,125 -100 rpm – op.22
CP.25 acc. time for 0,00...300,00 0,01 5,00 s – op.28
CP.26 dec. time for. -0,01...300,00 0,01 5,00 s – op.30
CP.27 S-curve time 0.00(off)...5.00 0,01 0.00(off) s – op.32
CP.28 torque reference source 0...6 1 2 – E cs.15
CP.29 abs. torque ref ±32000,00 0,01 LTK Nm – cs.19
CP.30 KP speed 0...32767 1 300 – – cs.06
CP.31 KI speed 0...32767 1 100 – – cS.09
CP.32 switching frequency 1...LTK 1 LTK – E uf.11
CP.33 relay output 1 / function 0...92 1 4 – E do.02
CP.34 relay output 2 / function 0...92 1 2 – E do.03
CP.35 proh. rot. stopping mode 0...6 1 6 – – pn.07
CP.36 E.EF stopping mode 0...6 1 0 – – pn.03
CP.3 inverter state
In parameter „inverter status“ the actual operating condition of the frequency inverter is
displayed (e.g. constant running forward, standstill). In the case of an error the current error
message is displayed, even if the display has already been reset with ENTER (error-LED
on the operator is still blinking). Status messages and information about the cause and
removal are to be found at the „Standard- and Interface Operator“ instruction manual.
