KEB COMBIVERT F5

EN - 31
CP-Parameters
CP.33 relay output 1 / function
CP.34 relay output 2 / function
CP.33/34 determine the function of the two relay outputs (X2A.24-26, X2A.27-29).
Value Function
0 off
1 on
2 run; also at DC-braking
3 ready (no error)
4 Fault relay
5 Fault relay (without auto-reset)
6 err.mess./abn.stopping
7 OL warning
8 OH warning
9 dOH warning
11 OHI warning
20 act. value = set value (CP.3 = Fcon, rcon, not at noP, LS, error, SSF)
21 acceleration (CP.3 = FAcc, rAcc, LAS)
22 deceleration (CP.3 = FdEc, rdEc, LdS)
23 act. rotation = set rotation
24 act. utilization > level
1)
25 abs.val. act.curr. > level
1)
27 actual value (CP.1) > level
1)
28 set value (CP.2) > level
1)
31 abs.val. AN1 > level
1)
32 abs.value AN2 > level
1)
34 set value AN1 > level
1)
35 set value AN2 > level
1)
40 hardw.curr. limit active
41 modulation on
47 ramp output value>level
1)
48 apparent current (CP.4) > level
1)
49 rot. forward (not at nOP, LS, abnormal stopping or error)
50 rot. reverse (not at nOP, LS, abnormal stopping or error)
51 OL2 warning
52 I-control limit active
53 n-control limit active
63 abs.val. ANOUT1 > level
1)
64 abs.val. ANOUT2 > level
1)
65 ANOUT1 > level
1)
66 ANOUT2 > level
1)
70 driver VCC active
73 abs.val. act.power > level
1)
74 active power > level
1)
No listed values are only for application mode.
1)
Switching level of CP.33 = 100; switching level of CP.34 = 4
