KEB COMBIVERT F5 Installation Manual

GB - 21
CP-Parameter
5. Parameter Descriptions
5.1 Basic/Compact/General/Application without encoder interface
Parameter Setting Range
Resolu-
tion
Default Unit
↵
Based
on
CP.0 Password input 0…9999 1 - - - ud.1
CP.1 Actual frequency display -400…400 0.0125 0 Hz - ru.3
CP.2 Set frequency display -400…400 0.0125 0 Hz - ru.1
CP.3 Inverter status 0…255 1 0 - - ru.0
CP.4 Apparent current 0…6553.5 0.1 0 A - ru.15
CP.5 Apparent current / peak value 0…6553.5 0.1 0 A - ru.16
CP.6 Utilization 0…65535 1 0 % - ru.13
CP.7 DC link voltage 0…1000 1 0 V - ru.18
CP.8 DC link voltage / peak value 0…1000 1 0 V - ru.19
CP.9 Output voltage 0…778 1 0 V - ru.20
CP.10 Minimal frequency 0…400 0.0125 0 Hz - op.6
CP.11 Maximum frequency 0…400 0.0125 70 Hz - op.10
CP.12 Acceleration time 0.00…300.00 0.01 5 s - op.28
CP.13 Deceleration time (-1=CP.12) -0.01…300.00 0.01 5 s - op.30
CP.14 S-curve time 0.00…5.00 0.01 0 s - op.32
CP.15 Boost 0.0…25.5 0.1 LTK % - uf.1
CP.16 Rated frequency 0…400 0.0125 50 Hz - uf.0
CP.17 Voltage stabilization 0…650 V (off) 1 0 V E uf.9
CP.18 Switching frequency 0…LTK 1 LTK - E uf.11
CP.19 Fixed frequency 1 -400…400 0.0125 5 Hz - op.21
CP.20 Fixed frequency 2 -400…400 0.0125 50 Hz - op.22
CP.21 Fixed frequency 3 -400…400 0.0125 70 Hz - op.23
CP.22 DC braking / mode 0…9 1 7 - E pn.28
CP.23 DC braking time 0.00…100.00 0.01 10 s - pn.30
CP.24 Max. ramp current 0…200 1 140 % - pn.24
CP.25 Max. constant current 0…200 1 200:off % - pn.20
CP.26 Speed search / condition 0…15 1 8 - E pn.26
CP.27 Quick stopping / ramp time 0.00…300.00 0.01 2 s - pn.60
CP.28
Response of ext. overtempera-
ture.
0…7 1 7 - - pn.12
CP.29 Analog output 1 / function 0…20 1 2 - E an.31
CP.30 Analog output 1 / amplication -20.00…20.00 0.01 1 - - an.33
CP.31 Relay output 1 / function 0…76 1 4 - E do.2
CP.32 Relay output 2 / function 0…76 1 27 - E do.3
CP.33 Relay output 2 / function ±30000.00 0.01 4 - - le.3
CP.34 Source of rotation direction 0…9 1 2 - E op.1
CP.35 AN1 set value selection 0…2 1 0 - E an.0
CP.36 AN1 zero point hysteresis -10.0…10.0 0.1 0.2 % - an.4
LTK=depending on power unit; E=ENTER parameter
