KEB COMBIVERT F5

EN - 26
CP-Parameters
1 absolute set frequency CP.2 0…100 Hz
2 actual frequency CP.3 0…±100 Hz
3 Setpoint frequency CP. 2 0…±100 Hz
4 output voltage CP.9 0…500 V
5 DC link voltage CP.7 0…1000 V
6 apparent current CP.4 0…2 • rated current
7 active current ru.17 0…2 • ±rated current
8…10 only application mode
11 absolute active current ru.17 0…2 • rated current
12 power stage temperature ru.38 0…100 °C
13 motor temperature ru.46 0…100 °C
14…18 only application mode
19 ramp output frequency ru.2 0…±100 Hz
20 absolute ramp output frequency ru.2 0…100 Hz
CP.31 Relay output 1 / function (terminals X2A.24...26)
CP.32 Relay output 2 / function (terminals X2A.27...29)
The switching level of CP.31 is pre-set to 100.00.
The switching level of CP.32 is adjusted by CP.33!
Val-
ue
Function
0 No function (generally off)
1 Generally on
2 run; also at DC-braking
3 ready (no error)
4 Fault relay
5 Fault relay (without auto-reset)
6 Warning or error message at abnormal stopping
7 OL warning
8 OH warning
9 External Overtemperature alert signal motor
11 Overtemperature alert signal interior OHI
12 Cable breakage 4...20 mA on analog input 1
14 max. constant current (Stall, CP.25) exceeded
15 max. ramp current (LA-Stop, CP.24) exceeded
16 DC-braking active
20 Actual value = set value (CP.3 = Fcon; rcon; not at noP, LS, error, SSF)
21 acceleration (CP.3 = FAcc, rAcc, LAS)
22 deceleration (CP.3 = FdEc, rdEc, LdS)
23 act. rotation = set rotation
24 Utilization (CP.6) > switching level
25 Active current > switching level
26 Intermediate circuit voltage (CP.7) > switching level
27 Real value (CP.1) > switching level
28 Set value (CP.2) > switching level
31 Absolute set value at AN1 > switching level
32 Absolute set value at AN2 > switching level
34 Set value at AN1 > switching level
