KEB COMBIVERT F5

EN - 41
Annex B
• “E Housing, Series COMBIVERT Cat. No. 12, 13, 14, 15 or 16 followed by
F5, followed by B or C, followed by 0, 1, 2 or 3, A, B, C or D, followed by E-,
followed by four sufxes
E Housing, Series COMBIVERT Cat. No. 12, 13, 14, 15 or 16 followed by
F6, followed by B or C, followed by 0, 1, 2 or 3, A, B, C or D, followed by E-,
followed by three sufxes and followed by 4 or E or J.
Motor Overtemperature Protection:
above drive models are not provided with load and speed sensitive overload
protection and thermal memory retention up on shutdown or loss of power (for
details see NEC, article 430.126(A)(1)”.
For 240 V models:
„Suitable For Use On A Circuit Capable Of Delivering Not More Than 10000 rms
Symmetrical Amperes, 240 Volts Maximum, when Protected by Fuses, see Instruc-
tion Manual for specied fuse details and alternate Branch Circuit Protection details.”
For 480 V models:
„Suitable For Use On A Circuit Capable Of Delivering Not More Than 10000 rms
Symmetrical Amperes, 480 Volts Maximum, when Protected by Fuses, see Instruc-
tion Manual for specied fuse details and alternate Branch Circuit Protection details.”
For all models:
Branch Circuit Protection: input fusing
Inverter model
F5/F6
Input
Voltage
(V)
UL 248
Fuse class RK5 or
J or CC
[A]
Semiconductor fuses
Cat. No.
(#)
12 480 / 3ph 25 50 140 06 25
13 240 /3ph 40 50 140 06 80
13 480 / 3ph 25 50 140 06 40
14 240 /3ph 50 50 140 06 100
14 480 / 3ph 30 50 140 06 50
15 480 / 3ph 40 50 140 06 80
16 480 / 3ph 50 50 140 06 100
(#) manufactured by Siba Sicherungen-Bau GmbH
