The voltage rating of the Class rated fuses shall be at least equal to the voltage
rating of the Drives.
Branch Circuit Protection:
Type E Self Protected Manual Motor Controllers for Drive series inverters F5-E and
F6-E.
Listed (NKJH) Type E Self Protected Manual Motor Controllers. Type and manufac-
turer and electrical ratings as specied below:
240V devices:
Inverter
model
F5/F6
Drive input
rating
Self Protected
Manual Motor Controller Type
and manufacturer
Self Protected
Manual Motor Con-
troller rating
13 240V/ 3ph PKZMO-32E, Eaton Industries 230V/ 3ph, 10 hp
14 240V/ 3ph PKZM4–50E, Eaton Industries 230V/ 3ph, 15 hp
480V devices:
Inverter
model
F5/F6
Drive input
rating (#)
Self Protected
Manual Motor Controller Type
and manufacturer
Self Protected
Manual Motor
Controller rating
12 480V/ 3ph PKZMO-25E, Eaton Industries 480Y/277V, 15 hp
13 480V/ 3ph PKZMO-25E, Eaton Industries 480Y/277V, 15 hp
14 480V/ 3ph PKZMO-25E, Eaton Industries 480Y/277V, 15 hp
15 480V/ 3ph PKZM4–40E, Eaton Industries 480Y/277V, 30 hp
16 480V/ 3ph PKZM4–40E, Eaton Industries 480Y/277V, 30 hp
(#) all Drives series which use a Self Protected Motor Controller rated
480Y/277V are suitable for 480y/277V sources only.
Only for F6 housing E series:
“For Connector CN300 on Control Board:
Only use KEB Cable assembly Cat.No. 00H6L41-0xxx or 00H6L53-2xxx (where any
digit) and use strain relief provisions as described below:”
