KEB COMBIVERT F5 Installation Manual

Annex B
GB - 88
Table for input fusing of inverters F5-A housing:
Inverter Input Voltage UL 248 Fuse Class
J or RK5 *
UL 248 Fuse Class
CC *)
[V] [A] [A]
05F5 240 / 1ph 10 10
05F5 240 / 1ph 6 5
07F5 240 / 1ph 15 20
07F5 240 / 1ph 10 10
05F5 400 / 480 / 3ph 5 ---
07F5 400 / 480 / 3ph 6 ---
09F5 400 / 480 / 3ph 10 ---
*) The voltage rating of the Class rated fudes (CC, J or RK5) shall be at least equal to the
voltage of the Drivers.
Branch Circuit Protection: Type E Self Protected Manual Motor Controllers for
inverters F5-A housing.
Cat. No. Drive Input
ating
Self Protected Manual Motor
Controller Type and manufac-
turer
Self Protected Manual
Motor Controller rating
05F5 240V / 1ph PKZMO-10E, Eaton Industries 230V, 1.5 hp
05F5 240V / 3ph PKZMO-6.3E, Eaton Industries 230V / 3ph, 1.5 hp
07F5 240V / 3ph PKZMO-16E, Eaton Industries 230V, 2 hp
07F5 240V / 1ph PKZMO-10E, Eaton Industries 230V / 3ph, 3 hp
