CP-Parameters
Value Function
50 rot. reverse (not at nOP, LS, abnormal stopping or error)
51 OL2 warning
52 I-control limit active
53 n-control limit active
63 abs.val. ANOUT1 > level
1)
64 abs.val. ANOUT2 > level
1)
65 ANOUT1 > level
1)
66 ANOUT2 > level
1)
70 driver VCC active
73 abs.val. act.power > level
1)
74 active power > level
1)
Unlisted values are only for application mode
1)
Switching level of CP.33 = 100; switching level of CP.34 = 4
CP.35 proh. rot. stopping mode
This parameter determines the reaction of the drive to terminal X2A.14 (F) and/or X2A.15
(R), which are programmed as limit switches. The reaction of the drive is shown in the
table below.
CP.35 Display Reaction Restart
0 E.PRx Immediate disabling of modulation
Remove fault,
reset
1 A.PRx
Quick stopping / disabling of modulation after
reaching speed 0
2 A.PRx Quick stopping / holding torque at speed 0
3 A.PRx Immediate disabling of modulation
Autoreset, if no fault
is present
4 A.PRx
Quick stopping / disabling of modulation after
reaching speed 0
5 A.PRx Quick stopping / holding torque at speed 0
6 none No effect to the drive, fault is ignored ! inapplicable
CP.36 E.EF stopping mode
With the external error monitoring external units can take direct inuence on the drive.
This parameter determines the response of the drive to a signal at terminal X2A.12 (I3)
according to the following table.
CP.36 Display Reaction Restart
0 E.PRx Immediate disabling of modulation
Remove fault,
reset
1 A.PRx
Quick stopping / disabling of modulation after
reaching speed 0
2 A.PRx Quick stopping / holding torque at speed 0
3 A.PRx Immediate disabling of modulation
Autoreset, if no fault
is present
4 A.PRx
Quick stopping / disabling of modulation after
reaching speed 0
5 A.PRx Quick stopping / holding torque at speed 0
6 none No effect to the drive, fault is ignored ! inapplicable
