GB - 7
Preface
1.6 Product description
The safety manual completes the installation manuals COMBIVERT G6 with the safety func-
tion STO. It contains safety-related supplements and regulations for the operation of COM-
BIVERT G6 in safety applications. The basic standards as well as application and country-
specicstandardsmustbeobservedfurthermore.Thestandardsreferredinthismanualmust
be observed supplementary. The safety function STO according to IEC 61800-5-2 contains:
• Safe torque off (Safe Torque Off - STO)
The safety function meet the requirements in accordance with performance level e (ISO13849-
1) and SIL 3 (IEC 61508 and IEC 62061). In case of proper project design, installation and
operation the safety function protects people against mechanical damages. COMBIVERT G6
inverters with integrated STO function correspond to the following numbers code:
Product code
xx G6 x x x - xxxx
A, B, C, D, H, I, K, L
Validity of
certicates
The certication of controllers with safety tech-
nology since 05.2013 is only valid if the material
numbercorrespondswiththespeciednumerical
code and the FS logo is printed on the type plate.
1.7 Part code
xx G6 x x x - x x x x
Cooling (not valid at customer/special version)
0 Air-cooling(housingC,D,E);air-cooling/atrear(housingA,B)
1 Flat rear
Control/keyboard/display (not valid at customer/special version)
0 Open-loop without keyboard/display A like 0 on ASCL hardware
1 Open-loop with keyboard/display B like 1 on ASCL hardware
2 SCL without keyboard/display
3 SCL with keyboard/display
4 ASCL without keyboard/display
5 ASCL with keyboard/display
Switching frequency; short time current limit; overcurrent cut-off
(not valid at customer/special version)
0 2 kHz 125 % 150 % 1 4 kHz 125 % 150 %
2 8 kHz 125 % 150 % 3 16 kHz 125 % 150 %
4 2 kHz 150 % 180 % 5 4 kHz 150 % 180 %
6 8 kHz 150 % 180 % 7 16 kHz 150 % 180 %
8 2 kHz 180 % 216 % 9 4 kHz 180 % 216 %
A 8 kHz 180 % 216 % B 2 kHz 180 % 216 %
Voltage, connection
further on next side
