20
POWERTRAIN SPECIFICATIONS________________
FASTENER TORQUE
Self-tapping screws for fan cover assembly 1-3Nm (9-26 lbs-in)
Locknuts for fan cover assembly 10-12Nm (8-9lbs-ft)
Self-tapping screws for air cover 1-3 Nm (9-26 lbs-in)
Lock nut for air cover 10-12Nm (8-9lbs-ft)
Self-tapping screw and nut for cylinder head cover vent 1-3Nm (9-26lbs-in)
Locknut for cylinder head cover 10-12Nm (8-9lbs-ft)
Locknut for cylinder head 15-18Nm (11-13lbs-ft)
Spark plug 15-18Nm (11-13lbs-ft)
Intake port bolts 10-12Nm (8-9lbs-ft)
Exhaust port bolts 10-12Nm (8-9lbs-ft)
Carburetor joint locknuts 10-12Nm (8-9lbs-ft)
Cooling fan locknuts 10-12Nm (8-9lbs-ft)
Flywheel locknut 45-50Nm (33-36lbs-ft)
Stator coil locknuts 6-8Nm (4-6lbs-ft)
Magneto locknuts 10-12Nm (8-9lbs-ft)
Locknuts for RH crankcase cover 10-12Nm (8-9lbs-ft)
Locknut for oil pump 5-9Nm (3-7lbs-ft)
Locknut for driven clutch assembly 55-60Nm (40-44lbs-ft)
Locknut for driven clutch hub 35-38Nm (26-28lbs-ft)
RH crankcase locknut 10-12Nm (8-9lbs-ft)
Engine pivot bolt 55-60Nm (41-44lbs-ft)
LH crankcase cover locknut 10-12Nm (8-9lbs-ft)
Self-tapping screws for LH crankcase cover vent 3-6Nm (2-4lbs-ft)
