49
LH CRANKCASE COVER
Removal
Cable clip and fender bracket (1 & 2)
LH Crankcase cover (3)
Dowel and gasket (4 & 5)
Installation procedure is opposite removal.
NOTE: after ensuring proper alignment, installation may be facilitated by gently tapping
cover into position with a rubber mallet. Upon starting all bolts, proceed to apply torque
in a modified star pattern, bringing them all to 8-9lbs-ft.
