KEEWAY 50cc Series User Manual

59
CHASSIS_______________________________________
TORQUE SPECIFICATIONS
Front Wheel/Fork
Axle Nut (1) 41-44lbs-ft
Fork Legs to Triple Clamp (4) 27-32lbs-ft
Brake Assembly Mount (2) 16-21lbs-ft
Handlebar
Handlebar to Triple Clamp (1) 27-32lbs-ft
Frame
Engine Bracket Mount (1) 28-32lbs-ft
Rear Shock to Frame (1) 28-32lbs-ft
Rear Wheel/Rear Shock
Axle Nut (1) 73-95lbs-ft
Rear Shock to Swing Arm (1) 17-21lbs-ft
Engine
Exhaust to Engine (2) 13-20lbs-ft
Expansion Chamber to Engine (1) 8-12lbs-ft
Engine to Engine Bracket (2) 28-32lbs-ft

KEEWAY 50cc Series Specifications

General

Cooling System	Air-cooled
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Tires Front	120/70-12
Tires Rear	130/70-12
Width	700 mm
Transmission	Automatic
Engine Type	Single-cylinder, 2-stroke
