Keithley 2000 Quick Start Guide

1-16 Return to Section Topics 2000-903-01 Rev. C / October 2007
Section 1: Introduction Model 2000 Digital Multimeter Quick Start Guide
IEEE-488.2 common commands and queries
Table 1-4
IEEE-488.2 common commands and queries
Mnemonic Name Description
*CLS
*ESE <NRf>
*ESE?
*ESR?
*IDN?
*OPC
*OPC?
*OPT?
*RCL <NRf>
*RST
*SAV <NRf>
*SRE <NRf>
*SRE?
*STB?
*TRG
*TST?
*WAI
Clear status
Event enable command
Event enable query
Event status register query
Identification query
Operation complete
command
Operation complete query
Option identification query
Recall command
Reset command
Save command
Service request enable
command
Service request enable query
Read status byte query
Trigger command
Self-test query
Wait-to-continue command
Clears all event registers and Error Queue.
Program the Standard Event Enable Register.
Read the Standard Event Enable Register.
Read the Standard Event Enable Register and
clear it.
Returns the manufacturer, model number,
serial number and firmware revision levels of
the unit.
Set the Operation Complete bit in the Standard
Event Status Register after all pending
commands have been executed.
Places an ASCII “1” into the output queue
when all pending selected device operations
have been completed.
Returns an ID code that indicates which
memory option is installed and whether or not
the optional scanner card is installed.
Returns the Model 2000 to the setup
configuration stored in the specified memory
location.
Returns the Model 2000 to the *RST default
conditions.
Saves the current setup to the specified
memory location.
Programs the Service Request Enable
Register.
Reads the Service Request Enable Register.
Reads the Status Byte Register.
Sends a bus trigger to the 2000.
Performs a checksum test on ROM and returns
the result.
Wait until all previous commands are executed.

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
