2260B Series Programming Manual
28
5. Enter the IP address and the port number of the
2260B. The port number is fixed at 2268.
6. Double click the Validate button.
5
6
7. Next configure the Alias (name) of the 2260B
connection. In this example the Alias is:
PS_DC1
8. Click finish.
