6-4 Replaceable Parts Model 2500 Service Manual
C394,C396,C594,C596 CAP, .01UF, 10%, 50V, CERAMIC C-491-.01
C397,C597 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C398,C598 CAP, 100UF, 20%, 16V, TANTALUM C-504-100
C406,C407,C606,C607 CAP, 100UF, ±20%, 200V, ALUM ELECT C-498-100
C412,C413,C612,C613 CAP, 47U, +50%, -20%, 160V, ALUM
ELEC
C-354-47
C414,C415,C418,C419,C614,C615,C618,C619 CAP, 2.2UF, ±20%, 200V, ALUM ELECT C-498-2.2
C416,C417,C616,C617 CAP, .01UF, 10%, 200V, CERAMIC C-472-.01
C501-C503,C505-C507,C510,C514,C520,C521 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C509,C513,C586,C602,C605 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C523,C524,C556,C557,C564,C608,C609,C611 CAP, 1UF, 10%, 500V, X7R C-525-.1
C531,C532,C542,C543,C546,C549-C555,C558 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C563,C566,C572,C574-C579,C591,C593 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C570 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C571,C573,C581,C592 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C587,C589,C590,C387,C389,C390 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C595,C318,C322,C327,C370,C518,C522,C527 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C601,C603,C604,C281,C315,C316,C515,C516 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
CR115,CR116,CR122-CR129 DIODE, DUAL SWITCHING, BAV99L RF-82
CR117,CR118,CR119,CR120,CR121 DIODE, DUAL COMMON ANODE
BAW56LT2
RF-98
CR302,CR502,CR303,CR503 ULTRA FAST BRIDGE RECTIFIER,
EDF1BM
RF-123
CR304,CR504 DIODE, CRB2-100 RF-148
CR309-CR312,CR314-CR319,CR509-CR512 DIODE, SWITCHING, MMBD914 RF-83
CR313,CR513 DIODE, DUAL HSM-2822T31 RF-95
CR514-CR519 DIODE, SWITCHING, MMBD914 RF-83
F101 POLYSWITCH, SMD030-2 FU-103
HS301-HS303,HS501-HS503 HEAT SINK HS-55
HS314,HS514 HEAT SINK HS-39
J1006 CONN, CIRCULAR DIN CS-762
J1007 CONN, D-SUB DUAL STACK M-F CS-1072-1
J1008 CONN, RIGHT ANGLE, 24 PIN CS-501
J101,J103 CONN, BERG CS-339
J1014 CONN, HEADER STRAIGHT SOLDER
PIN
CS-368-16
J102 CONN, HEADER STRAIGHT SOLDER
PIN
CS-368-10
J104 CONNECTOR, HEADER CS-784-4
J105,J302,J502 LATCHING HEADER, FRICTON, SGL
ROW
CS-724-3
Table 6-1 (cont.)
Mother board parts list
Circuit designation Description
Keithley
part no.
