Keithley 3720-ST

Series 3700A System Switch/Multimeter Reference Manual Section 5: Switching and scanning
3700AS-901-01 Rev. D/June 2018 5-9
Figure 79: Web interface cards list
3. To close a channel, click the channel. The display of the channel depends on the card that you
have installed. Some examples are shown here.
Figure 80: Selecting, closing, and opening a channel from the web interface
Figure 81: Selecting, closing, and opening a channel from the web interface
