Series 3700A System Switch/Multimeter Reference Manual Section 2: Installation
3700AS-901-01 Rev. D/June 2018 2-3
Weight
The weights of the Series 3700A, plug-in cards, and the screw terminal adapter are provided in the
following table.
Component
Weight
Model 3706A mainframe
6.12 kg (13.5 lb)
Plug-in card, average
1.36 kg (3 lb)
Screw terminal adapter, average
0.45 kg (1 lb)
You can calculate the total weight of your Series 3700A using the weights of the individual
components in your system. For example, if you have a Series 3700A mainframe with six plug-in
cards and three adapters installed:
6.12 kg + (1.36 kg  6) + (0.45 kg  3) = 15.63 kg
(13.5 lb + (3.0 lb  6) + (1.0 lb  3) = 34.45 lb)
Rack-mounting instructions
The following instructions are for configurations with up to two plug-in cards. If you have more than
two cards installed in the Series 3700A mainframe, you must use the optional Model 4288-10 Rear
Support Mount Kit in a fixed installation.
Tools required
• Medium (#2) Phillips-head screwdriver
Parts list
The table below lists the hardware that is supplied with the Series 3700A.
Item description
Part number
Quantity
Cage nut
FA-148
4
10-32  5/8 in. Phillips truss-head screw
n/a
4
